MediaTek Dimensity 9400e specifications, expected benchmark scores

MediaTek Dimensity 9400e is a new midrange chip from the Dimensity 9400 series. It is an enhanced version of the Dimensity 9300+ chipset. It was launched at the OnePlus Game Strategic Communication Conference in China, and the first phone to adopt it will also be a OnePlus phone. Find the full list of expected phones with this chip. You can also learn about the MediaTek Dimensity 9400e specifications and benchmark details below.

MediaTek Dimensity 9400e specifications, benchmarks

  • Dimensity 9400e comes with 1 ARM Cortex-X4 prime core with up to 3.4GHz clock speed, 3 ARM Cortex-X4 performance cores up to 2.85GHz and 4 Cortex-A720 efficiency cores running at up to 2.0GHz frequency. The chip is based on TSMC’s third-gen 4nm process node.
  • The performance is aided by 8MB L3 cache and 10MB SLC cache.
  • For graphics, you get Arm Immortalis-G720 MC12 GPU.
  • The chip sports MediaTek APU 790 with Generative AI capabilities.

Here are its specs listed in a tabular format:

BASISSPECS
Process4nm
ManufacturerTSMC
Cores8 (octa-core)
CPU Structure

1 x ARM Cortex-X4 cores up to 3.4GHz

3 x ARM Cortex-X4 cores up to 2.85GHz

4 x Cortex-A720 cores at up to 2.0GHz

CPU max frequency3,400MHz
Storage typeUSF 4.0+ MCQ
Memory typeLPDDR5T
Max. display resolution

WQHD at 180Hz

4K up to 120Hz

Max. camera sensor320MP
Max. video capture8K at 30FPS (7690 x 4320)
CPU Bit64-bit
GPUArm Immortalis-G720 MC12
NPUMediaTek NPU 790
ConnectivitymmWave 5G, Wi-Fi 7, Bluetooth 6.0, GPS, NavIC L5

  • The direct competitor to Dimensity 9400e could be the Snapdragon 8s Gen 4 from the Qualcomm stable.
  • As per tipster Digital Chat Station, the OnePlus Ace 5V with this chip has scored up to 2.1 million points on AnTuTu, and around 95 FPS on GFXBench’s Aztec 1440p graphics test.

Phones with MediaTek Dimensity 9400e (expected)

  • OnePlus Ace 5 Racing Edition
  • OnePlus Ace 5V
  • OnePlus Nord 5
  • Realme Neo 7 Turbo
  • Vivo X200 FE

We’ll update this article with the Dimensity 9400e benchmarks and other details as we have them. Keep reading.

FAQ

When was the MediaTek Dimensity 9400e launched?

Dimensity 9400e was launched on May 14th, 2025. OnePlus is the first brand to release a phone with this chip.
