TCL 505

+ Compare

71%

View All Photos (5)

₹9,990

Key Specs

Android v14

Performance

(Good)

MediaTek Helio G36
Octa core (2.2 GHz, Quad Core + 1.6 GHz, Quad core)
4 GB RAM

Display

(Very Good)

6.75 inches (17.15 cm); IPS LCD
720x1600 px (HD+)
90 Hz Refresh Rate
Bezel-less with waterdrop notch

Rear Camera

(Good)

Dual Camera Setup
- 50 MP Wide Angle Primary Camera
- 2 MP Depth Camera
LED Flash
Full HD @30fps Video Recording

Front Camera

(Very Good)

5 MP
Full HD @30 fps Video Recording

Battery

(Very Good)

5010 mAh
USB Type-C port

General

SIM1: Nano, SIM2: Nano
5G Not Supported
128 GB Storage, Expandable upto 512 GB

Add To Compare See Full Specs

TCL 505 Specifications

General Performance Display Design Rear Camera Front Camera Battery Storage Network & Connectivity Multimedia Sensors

General
Operating System	Android v14

Performance (Good)
Chipset	MediaTek Helio G36
Processor	Octa core (2.2 GHz, Quad core, Cortex A53 + 1.6 GHz, Quad core, Cortex A53)
Architecture	64 bit
Fabrication	12 nm
Graphics (GPU)	PowerVR GE8320
RAM	4 GB

Display (Very Good)
Display Type	IPS LCD
Screen Size	6.75 inches (17.15 cm)
Resolution	720x1600 px (HD+)
Brightness	400 nits
Refresh Rate	90 Hz
Aspect Ratio	20:9
Pixel Density	260 ppi
Screen to Body Ratio (calculated)	85.25 %
Bezel-less Display	Yes with waterdrop notch
Screen to Body Ratio (claimed by the brand)	90.08 %

Design
Height	168.29 mm
Width	76.67 mm
Thickness	8.32 mm
Weight	190 grams

Rear Camera

(Good)

Resolution

Camera	MP	Aperture	Lens Features	Sensor Size	Pixel Size
Primary	50 MP	f/1.8	Wide Angle(79° field-of-view)	1/2.55"	0.7µm
Secondary	2 MP	f/2.4	Depth	1/5.0"	1.75µm

Autofocus

Yes, Phase Detection autofocus

Flash

Yes, LED Flash

Image Resolution

8150 x 6150 Pixels

Settings

Exposure compensation

Shooting Modes

High Dynamic Range mode (HDR)

Camera Features

Auto Flash
Face detection
Touch to focus

Video Recording

1920x1080 @ 30 fps

Front Camera

(Very Good)

Resolution

Camera	MP	Aperture	Pixel Size
Primary	5 MP	f/2.2	1.12µm

Video Recording

1920x1080 @ 30 fps

Battery (Very Good)
Capacity	5010 mAh
Battery Type	Li-Polymer

Storage
Internal Storage	128 GB
Expandable Storage	Yes, Up to 512 GB

Network & Connectivity

SIM Slot(s)

Dual SIM

SIM Type

SIM1: Nano, SIM2: Nano

Network Support

5G Not Supported, 4G

VoLTE

Yes

SIM 1

4G bands

Expand

Bands	Features
4G bands	TD-LTE 2600(band 38) / 2300(band 40) / 2500(band 41)
	FD-LTE 2100(band 1) / 1800(band 3) / 2600(band 7) / 900(band 8) / 700(band 28) / 850(band 5) / 800(band 20) / 850(band 26)

SIM 2

4G bands

Expand

Bands	Features
4G bands	TD-LTE 2600(band 38) / 2300(band 40) / 2500(band 41)
	FD-LTE 2100(band 1) / 1800(band 3) / 2600(band 7) / 900(band 8) / 700(band 28) / 850(band 5) / 800(band 20) / 850(band 26)

Wi-Fi

Yes, Wi-Fi 5 (802.11 a/b/g/n/ac) 5GHz

Wi-Fi Features

Wi-Fi Direct, Mobile Hotspot

Bluetooth

Yes, v5.1

GPS

Yes with A-GPS, Glonass

NFC

Yes

Multimedia
Stereo Speakers	Yes
Audio Jack	3.5 mm

Sensors
Fingerprint Sensor	Yes
Fingerprint Sensor Position	Side
Other Sensors	Light sensor, Proximity sensor, Accelerometer

            TCL 505 Key Highlights

                  Processor
                  MediaTek Helio G36

                  RAM & Storage
                  4 GB RAM + 128 GB

                  Display
                  6.75", 720 x 1600 Resolution

                  Rear Camera
                  50 MP + 2 MP

                  Front Camera
                  5 MP

                  Battery
                  5010 mAh
